Holzstar (5150713) Woodbandsaw HBS 713 S
SKU 5150713
VAT Included
0% VAT for Businesses with an EU VAT Number! Available during checkout.
Product Overview:
| Dimensions and weights | |
|---|---|
| Length (product) approx. | 1500 mm |
| Width/depth (product) approx. | 975 mm |
| Height (product) approx. | 2260 mm |
| Net weight approx. | 400 kg |
| Extraction port | |
| Extraction port diameter | 2 x 120 mm |
| Work top(s) | |
| Work table length | 900 mm |
| Work table width | 700 mm |
| Work table height | 940 mm |
| Work table extension length | 200 mm |
| Work table extension width | 700 mm |
| Work table pivot | 0 ⌀ 45 ° |
| Work table pivot explanation | For safety reasons, a holding device / stop must be fitted from 20° to prevent the wood from slipping! |
| Electrical Data | |
| Supply voltage | 400 V |
| Mains frequency | 50 Hz |
| Delivery power | 4,0 kW |
| Cutting ranges | |
| Max. cutting height 90° | 430 mm |
| Max. cutting height 45° | 258 mm |
| Max. cutting width with stop | 595 mm |
| Max. cutting width without stop | 700 mm |
| Saw band | |
| Saw band speed(s) | 1560 m/min |
| Flywheel diameter | 710 mm |
| Saw band length | 5020 mm |
| Saw band length min. | 5010 mm |
| Saw band length max. | 5030 mm |
| Saw band width | 38 mm |
| Saw band width max. | 50 mm |
| Saw band thickness | 0,65 mm |
| Saw band guide | High quality, fixed saw blade guide |
- Mitre gauge
- Saw band
- Push stick
- EAN: 4036351286547
- Custom Number: 84659110
- Comprimento: 2250 mm
- Altura: 1145 mm
- Largura: 745 mm
- Peso Bruto: 460 kg
- Peso Líquido: 400
