Extraction Device For Metal Grinding Machines Metallkraft (AS 4003 W)
SKU 4421400
VAT Included
0% VAT for Businesses with an EU VAT Number! Available during checkout.
Product Overview:
- Suitable for wet grinding machines.
- Filter area visible through transparent plastic windows.
| Dimensions and weights | |
|---|---|
| Extraction duct diameter | 300 mm |
| Length (product) approx. | 970 mm |
| Width/depth (product) approx. | 1134 mm |
| Height (product) approx. | 2320 mm |
| Fan wheel diameter | 500 mm |
| Net weight approx. | 300 kg |
| Max. height (product) ca. | 2390 mm |
| Intake capacity | |
| Suction performance with dust bag/hoses | 4000/4500 m³/h |
| Electrical Data | |
| Drive motor output | 4,0 kW |
| Supply voltage | 400 V |
| Mains frequency | 50 Hz |
| Noise emission | |
| Sound pressure level max. | 84 dB(A) |
- EAN: 4036351304821.
- Custom Number: 84798997.
- Comprimento: 1050 mm.
- Altura: 1400 mm.
- Largura: 2400 mm.
- Peso Bruto: 330 kg.
- Peso Líquido: 315 kg.
