Unicraft (6770036) Powerstation PPS 3600 M

Description

• No exhaust fumes or noise
• Extremely large battery capacity with 5376 Wh
• Built-in lithium iron phosphate battery extremely durable and temperature-resistant
• More than 2500 charging cycles possible
• LCD screen for easy operation and display
• Charging via 230 V connection
• Connected devices protected by intelligent battery management system
• Completely maintenance-free
• Robust tubular lattice frame for outdoor use and construction site operation
• Mobile thanks to four large solid rubber tires

Technical data

Dimensions and weights

• Length (product) approx.: 597 mm
• Width/depth (product) approx.: 476 mm
• Height (product) approx.: 585 mm
• Net weight approx.: 68 kg

Battery

• Battery capacity: 5376 Wh
• Charging cycles (Capacity > 80%): > 2000
• Discharge temperature: -10 – 40 °C
• Battery type: LiFePo4
• Charging time to 100% battery with solar panel: 23 (2 x 200 W) h
• AC input: 220 - 240 V, 50 - 60 Hz, 2200 W
• Charging time to 100% battery with 230 V AC: 2.8 h

Drive

• Running time at 50% load: 2.9 h
• Running time at 100% load: 1.4 h
• Sound power level Lw: 54 dB(A)

Equipment

• Management system: Deep discharge, overvoltage, overcharging, short circuit, overtemperature, undertemperature, fast charging function of the Power Station, UPS function (uninterruptible power supply)
• Display: LCD

Power generator

• Generator IP degree of protection: IP23
• Socket IP degree of protection: IP 44

Powerstation

• Output AC socket: 3 x 230 V / 50 Hz / 3600 W (7200 W peak)

Product information EU 2023/2854

• Type of the generated data: Usage data
• Format of the generated data: Common, machine-readable formats such as JSON
• Amount of data: Up to 5 MB
• Continuous data generation in real time: Yes

Transport info

• EAN: 4036351360698
• Customs number: 85076000
• Length: 646 mm
• Height: 660 mm
• Width: 420 mm
• Gross weight: 74.5 kg
• Net weight: 68 kg
